What are the general troubleshooting methods for Diesel generator set Generator Set general troubleshooting 1. After pressing the start button, the unit does not respond or rotates very slowly 1. Possible cause: The starting battery is insufficient Starter battery connection and plug loose Intermediate relay failure starter motor failure 2. Processing method: check the charge of the starting battery Check and fasten the starter battery wire and plug Check whether the intermediate relay works normally overhaul starter motor 2. The engine can rotate to a certain speed, but cannot ignite 1. Possible cause: No oil is ejected from the fuel injector (poor fuel supply) Fuel system leaks air The injection time of the fuel injection pump is inaccurate or the fuel injection pump is faulty 2. Treatment method: check whether there is air leakage or blockage in the oil circuit from the daily fuel tank to the fuel injection pump Open the exhaust screw to check the oil outlet Retry fuel injection Replace fuel injection pump and try again 3. Shut down after starting 1. Possible reasons: poor oil circuit, clogged filter, failure of oil pump Air filter heavily clogged Fuel injector failure temperature is too low 2. Treatment method: Check the smoothness of the oil circuit, replace the diesel filter if necessary, check the air filter, and replace it if necessary Adjust fuel injectors, replace if necessary 4. The Generator Set engine is not working properly 4.1 black smoke 1. Possible cause: The air filter is seriously blocked Wrong grade of fuel Exhaust back pressure too high Injection pump failure fuel injector bite Insufficient engine cylinder compression 2. Treatment method: check the air filter and replace it if necessary Check fuel quality (use Chinese light 0# diesel) Check the fuel supply of the fuel injection pump and readjust Check the atomization condition of the fuel injector Check whether the cylinder compression force is normal 4.2 Blue smoke or white smoke 1. Possible reasons: Improper selection of lubricating oil grade, excessive oil level Short startup time, engine temperature is too low Worn piston rings, supercharger failure 2. Treatment method: Check whether the lubricating oil is too thin, and check whether the oil level is within the specified range No need to deal with, the unit can run for a little longer Check the gap between the piston ring and the cylinder and the gap between the piston ring groove and whether the supercharger is working normally 4.3 Engine running unstable 1. Possible reasons: poor oil supply or air in the oil circuit Fuel injection pump or injector failure Air filter partially clogged 2. Treatment method: Check whether the oil circuit is unobstructed, whether the oil pipe joint is loose, whether the fuel filter is blocked, check the fuel injection timing of the fuel injection pump, whether the fuel pump rack is flexible, and check the atomization status of the fuel injector nozzle to check the cleanliness of the air filt...

What are the precautions for the design of exhaust system of Diesel generator exhaust system   The exhaust of Diesel generator is not only harmful but also high temperature, so the design of exhaust system should be paid special attention   If the back pressure of the exhaust system on the engine exceeds the specified value, the performance of the engine will be affected and the maintenance interval will be shortened   The shorter the exhaust system, the smaller the resistance (and back pressure), and the bending parts within the system have a significant impact on the resistance. The maximum allowable resistance of the exhaust system is   R=450 mmH20: All models except SR.6D   600 mmH20: SR   816 mmH20: 6D   The resistance is measured at the outlet of the turbocharger   The recommended material for the exhaust pipe is carbon steel pipe (non galvanized)   1.1 Calculation of exhaust resistance and determination of exhaust pipe diameter   The exhaust resistance is affected by exhaust pipelines and silencers, etc   The exhaust resistance of the pipeline is obtained from the following equation   Pipe Diameter  Insisde Diameter External Diameter A B 150 200 250 300 350 400 450 500 6 8 10 12 14 16 18 20 155.2 204.7 254.2 304.7 339.8 390.6 441.4 492.2 165.2 216.3 267.4 318.5 355.6 406.4 457.2 508.0

1. The daily Fuel tank of Cummins generator set must be equipped with 1000L oil tank. A low oil level switch must be installed in the oil tank and warning signals for the 20% and 50% oil levels in two stages must be set.   2. The daiy fuel tank of Cummins generator set must be manufactured in accordance with national standards, using 4-6mm thick quality steel plates, with disc and flange shaped ends, all of which are welded.     3. The fuel tank of Cummins generator set must be equipped with a cover plate, oil level gauge, oil filling pipe sealing cap, fire extinguisher, ventilation cap, drip tray, slag discharge pipe, oil level switch, overflow pipe, manhole, oil storage gauge, etc. The oil storage gauge must be in the shape of a disc with clear markings of comparable dimensions to indicate the oil storage capacity, such as empty, 1/4, 1/2, 3/4, and full positions. The calibration of the fuel gauge must be demonstrated on site.   4. Cummins generator sets must be equipped with mesh filters that do not exceed 120 mesh holes on the oil outlet.   5. If the static pressure of the Cummins generator set oil tank is not sufficient for the selected engine, auxiliary electric oil transfer pumps and their auxiliary pipelines and related power sources must be provided to transport oil from the main oil tank to the engine. All electrical devices of the oil pump, including switchgear, motor starters, and cable terminals, must be explosion-proof.       6. A "close" valve manually operated by a pull wire must be installed on the fuel tank and engine oil supply pipe of the Cummins generator set for shutdown outside the machine room in case of an accident.       7. The oil supply and return pipelines of the Cummins generator set must be 50mm away from the surface with a temperature exceeding 200 ℃. If a soft oil pipe is supplied, the selected material must withstand a high temperature of 250 ℃.       8. A half cycle rotating hand operated oil pump must be installed on the oil tank of the Cummins generator set, accompanied by a sufficiently long inlet hose, valve, tee, and cock.
